150w Solar Street Light

1.High-brightness full-color display with all-weather visibility guarantee
2.Modular quick-install structure for easy installation
3.Full-spectrum high-color-rendering LED
4.IP65 protection rating
5.High-frequency PWM dimming

Send Inquiry

Description

Product Introduction

◎Smart LED screen: The 150W solar street light is equipped with a P3.0 high-brightness full-color screen, supporting dynamic brightness adjustment, intelligent screen splitting, and remote content management. Compared with IP54, the IP65 protection rating significantly improves dustproof and waterproof performance as well as adaptability to extreme environments, ensuring stable display around the clock.

◎Ease of installation: Through a snap-on lamp pole interface, a universal ball joint solar panel bracket, and a drawer-type battery compartment design, it achieves 30-minute rapid deployment, free angle adjustment, and 5-minute battery replacement, significantly reducing installation and maintenance costs.

◎High color rendering: Adopting full-spectrum LED chips and microprism lenses, with a color rendering index CRI≥80 and illuminance uniformity of 0.8. Combined with 3kHz high-frequency PWM dimming technology, it balances efficient lighting and visual comfort, suitable for healthy lighting needs in various scenarios.

Smart LED Screen

1.High-Brightness Full-Color Display

◎Dynamic Brightness Adjustment: Equipped with a photosensitive sensor (range 0.1-100,000lux) to monitor ambient illuminance in real time, the screen brightness automatically adjusts between 1,000-5,000cd/m² (traditional LED screens only reach 800-1,500cd/m²). This ensures clear visibility of text and images even under direct noon sunlight (illuminance ≥100,000lux).

◎Wide Viewing Angle Design: Adopts SMD three-in-one LED packaging (integrating red, green, and blue chips in a single package) combined with polarizer technology, expanding the horizontal viewing angle to 160° (traditional through-hole LEDs only offer 120°). This meets the multi-angle viewing needs of pedestrians and vehicles on both sides of the road.

◎Low-Power Driving: Utilizes a common cathode driver architecture (voltage distribution: red 1.8V, green/blue 3.2V), saving 30% energy compared to common anode architectures. Combined with PWM dimming technology (refresh rate ≥1,920Hz), it eliminates flicker while limiting screen power consumption to within 15W (10% of the total system power).

2.Intelligent Content Management System

◎Local Cache Mechanism: Built-in 8GB eMMC storage chip can store over 500 programs. When the network is interrupted, it automatically switches to local playback mode, ensuring continuous information dissemination

◎Smart Screen Splitting: Supports dividing the screen into 2-4 independent zones to display different content simultaneously (e.g., public service ads on top and real-time weather updates scrolling below), increasing information density and communication efficiency.

Enhanced Environmental Adaptability

To withstand harsh outdoor conditions, the screen incorporates the following protective measures:

◎Triple Protection Treatment: LED modules are coated with 50μm-thick conformal coating, passing salt spray tests (GB/T 2423.17-2008, 96h) and damp-heat cycle tests (GB/T 2423.4-2008, 10 cycles) to prevent moisture and salt spray from corroding circuits.

◎Temperature Control System: Integrates a 10W thermoelectric cooling chip and an NTC 10kΩ temperature sensor. Cooling activates when the screen temperature exceeds 45℃, and heating engages below 5℃, ensuring operation within -20℃ to +60℃.

◎Lightning Protection: A gas discharge tube (GDT) and metal oxide varistor (MOV) are added at the power input, withstanding 8/20μs waveform and 20kA surge current to prevent lightning damage to control circuits.

Comparison Table: IP65 vs. IP54 Protection Ratings

Protection Level	Dust Resistance	Water Resistance	Typical Failure Modes (Low-Grade Products)	Application Scenario Differences
IP54	Prevents harmful dust accumulation (Level 5)	Resists splashing water (no harm from splashes in any direction)	Internal dust buildup causing poor heat dissipation; water ingress in rainy seasons leading to short circuits	Only suitable for dry, low-dust indoor or semi-outdoor environments
IP65	Completely dust-tight (Level 6)	Resists water jets (6.3mm nozzle, 2.5m distance, 3-minute spray)	Maintains display clarity and stability even in sandstorms and heavy rains	Suitable for complex outdoor environments like urban roads, industrial parks, and coastal areas
